Proximal humeral fractures frequency is increasing, particularly in women aged older than 65 years, due to the lengthening of the average life and to the increase in osteoporosis.1–4 The evidences that surgical treatment is superior to conservative treatments, even for displaced fractures, are not clear.5,6 The latest Cochrane review suggests that non-operative management might have similar functional outcomes to operative management with lower risks of complications and reoperation.7,8 Moreover, there is no agreement about which type of fracture should be surgically treated, which type of surgery should be performed and which rehabilitation programs should be suggested.9 This high variability about surgical indication and type of surgery is present even among regions of the same country, leading to substantial variation worldwide in the management of this common injury. Generally, conservative treatment of proximal humerus displaced fractures, lead to bone healing in more than 90% of patients (malunion), with restriction of active range of motion, but acceptable functional results in elderly people.10 Surgery is usually indicated in more active patients with higher functional requests. Surgical treatment is associated with an higher complication rate, in confront to conservative treatment, such as: nonanatomic reduction, humeral head screws perforation, secondary displacement of the fracture, avascular necrosis, infection, greater tuberosity resorption and secondary cuff deficiency, stiffness and reintervention.11 In the last '90 and early 2000s, the market popularized modular dedicated humeral prosthesis and locking plates with polyaxial screws, anyway their use, accompanied by encouraging biomechanical studies in the laboratory, did not show a significant reduction in postoperative complication.12 Moreover, the Neer classification,13,14 which is the most used classification system, does not allow to define the type of treatment or to predict the clinical results.15 Recently, a new classification system based on Control Volume (CV) theory has been described.16,17 The CV theory and its classification system are the result of a mathematical approach to the three-dimensional pattern of the fracture, which evaluate the head displacement, the amount of bone loss and, the comminution of the medial and lateral humeral columns in the metaphysis. The CV theory helps to define a severity grade of the fracture which could help the surgeon to understand the best treatment option. The purpose of this article is to evaluate the therapeutic and prognostic predictive value of the CV severity grade in confront to the Neer classification.


All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee and with the 1964 Helsinki declaration and its later amendments or comparable ethical standards.

Informed consent was obtained from all individual participants included in the study.

We retrospectively collected the data of all patients affected by a closed displaced proximal humerus fracture, admitted in a single Hospital emergency department from 2013 to 2020. From this population, we selected all patient aged older than 65, which performed a CT scan before the treatment decision. Exclusion criteria were: open fracture, polytrauma, associated scapula, clavicular or humeral shaft fracture, previous shoulder surgery and pathological fractures. According to these criteria, eighty patients were included in the study. The radiological examinations were retrospectively analyzed by two orthopedic surgeons, blinded to the patient treatment or data, asking to classify the fracture according to the Neer and the CV criteria. The CV criteria were: the head displacement, the amount of bone loss and, the comminution of the medial and lateral humeral columns in the metaphysis and humeral head. The output evaluations of CV criteria defined three grades of fracture severity: low, medium and high. The therapeutic treatment of each patient was recorded. A telephonically interview with Simple Shoulder Test (SST) was used to evaluate the final clinical outcome.

Statistical Analysis

Statistical analysis was performed using Statistical Package for Social Sciences (SPSS) Version 20.0 (IBM, Armonk, NY, USA). The values were tested for normal distribution using the Kolmogorov–Smirnov test and the Shapiro–Wilk test. Univariate comparisons of dichotomous data were performed with the use of the chi-square or Fisher exact test, while the T-test was used to compare group means with SD. Multiple regression was also used to evaluate the effect of the test variables on the values of the dependent variables. A two-sided p-values were calculated. The level of significance was defined as p < 0.05.


We identified eighty patients eligible for the study, according to the inclusion and exclusion criteria. Sixty-four patients (80%) were available for a telephonic evaluation, whether sixteen patients (20%) were lost at the follow-up and were excluded from the study. Mean age was 74 years (66-85). There were 19 males and 45 females. Mean follow-up was 4 years (1 to 7). Fracture types were classified according to Neer as two-part fracture in 6 cases (9%), as three-part fracture in 25 cases (39%), as four-part fracture in 33 cases (51%). According to the CV criteria, the severity grade was evaluated as low in 23 cases (36%), medium in 13 cases (20%) and high in 28 patients (44%). Fifteen patients (23,5%) were treated conservatively, with immobilization for 4 weeks before to start physiotherapy; forty-nine (76,5%) surgically. Three patients (4,5%) were treated with closed reduction and percutaneous osteosynthesis with Kirschner wires. One (1,5%) patient was treated with open reduction and synthesis with a locking plate. Nine patients (14%) were treated with an endomedullary autologous iliac crest bone graft and locking plate. Eight patients (12,5%) were treated with a titanium endomedullary cage and locking plate.18 Twenty-eight cases (44%) were treated with reverse prosthesis. In the immediate postoperative period, we did not observe any vascular complications. One patient need postoperative intensive care. In three patients we observed a postoperative temporary axillary palsy. Mean inpatient time was 3,5 days (±2,5). SST values are reported in table 1. The statistical regression test demonstrated that the severity grade (p<0,05) correlates better than the Neer classification (p=0,35) to the type of treatment. Indeed, no patient with a low severity grade was treated with a reverse prosthesis and the 85% of the conservatively treated patients are in the group graded as low severity grade. On the contrary, reverse prosthesis and conservative treatment were used with a similar frequency in 2-, 3- and 4- part fractures. In particular, we observed several 2-part fractures with high (Fig. 1) and medium (Fig. 2) severity grade characterized by calcar fracture and lateral comminution. On the other side, better SST values were not statistically associated to a lower severity grade neither to the Neer classification. Only if we calculate the SST values for a specific group of treatment we could find a significative correlation between severity grade and clinical outcomes.

Table 1.Clinical outcomes according to the type of treatment measured with Simple Shoulder Test.
Simple Shoulder Test score results
Treatments Frequencies Min Max Mean 95% CI
RSA 28 33% 100% 76% (0,69;1)
ORIF 18 50% 100% 78% (0,73;1)
CRPO 3 67% 100% 85% (0,79;1)
NO 15 67% 92% 75% (0,7;1)

(RSA revers shoulder arthroplasty, ORIF open reduction internal fixation with plate and screws, CRPO closed reduction and percutaneous fixation, NO non operative treatment)

Figure 1
Figure 1.

A) anteroposterior radiographs and B) 3D computed tomography showing a 2-part fracture with posterior calcar fracture and lateral comminution classified as high severity grade

Figure 2
Figure 2.

A) anteroposterior radiographs and B) 3D computed tomography showing a 2-part fracture with posterior calcar fracture and lateral comminution classified as moderate severity grade, requiring a surgical treatment with open reduction, internal fixation with plate and screws

According to our results, we try to create a therapeutic algorithm based on the control volume criteria. We suggest using an endomedullary graft in case of varus displacement or medial column bone loss. In case of impacted forms with penetration of cortical diaphysis in the humeral head and conservation of the head position, even in case of lateral column comminution, the conservative treatment allows a very good result. In case of comminution of the lateral column and loss of calcar in the posterior side with the head impacted in varus position reverse prosthesis is the best option. The comminuted lateral column can be the cause of insufficient healing and loss of external rotation both in case of osteosynthesis and reverse or anatomical prosthesis.


The main finding of our study is that the use of Control Volume severity grade could help to define the stability and the complexity of proximal humerus fracture and, consequently, the better type of treatment. The therapeutical choice, of course, should take into account also several patients factors, such as: age, functional requests, comorbidities, expectative.19 Another important aspect of our study, is that displaced proximal humeral fractures cannot be evaluated just with plain radiographs, even if performed with the trauma series views. The use of a CT-scan and of a 3D model evaluation let the surgeon knows the real position of the humeral head, the measurement of anterior or posterior head tilting, the percentage of bone loss of the calcar. The amount of comminution is a key point, especially when referred to the calcar. Calcar comminution significantly decreases the stability of fracture reconstruction and gives direct information on the technical demand of fracture repair. On the other side, the Control Volume classification has some critical points. First, it is difficult to calculate the accurate topographic evaluation of bone loss without the help of specific researchers. Second, similar head displacement with equivalent bone loss could be associated with different severity, due to high comminution or different topographical involvement. This means that, the Control Volume measurements are not easy to evaluate and requires experts support. However, we believe that the spread of this preoperative study of the fracture, could reduce the tendency to treat indiscriminately with a reverse prosthesis all the displaced proximal humerus fracture associated to bone loss. According to the Control Volume severity grade, even fractures characterized by significant fragments displacement with posterior and superior displacement of the greater tuberosity equal or superior to 5 mm, could be treated non-operative, if the humeral head remains in a neutral position. The use of conservative treatment and of osteosynthesis, for the right fracture type, could reduce the complication, historically observed with these types of treatment, especially in case of bone fragility.10–12 We believe that previous studies demonstrating no difference between conservative and surgical treatment have not specifically assessed the type of fracture. The PROHFER study, for example, assessed only the surgical neck fracture by plain radiographs.5,6 Finally, the Control Volume criteria and the severity grade, in our series could predict the clinical outcome for patients treated with the same procedure. For patients treated with reverse prosthesis, the clinical outcomes are directly related to the healing of the tuberosities around the prosthetic stem. One of the factors influencing the severity grade is the multi-fragmentation of the greater tuberosity. In fact, in these cases, despite the accurate reconstruction of the tuberosity and the use of bone chips to fill the interface between cortical tuberosity and prosthesis, the external rotation was less effective than when the great tuberosity is intact or with a large fragment.20 This study has several weaknesses: it is a retrospective study, including a relatively small number of patients. The use of Control Volume criteria should be tested in prospective multicentric observational studies.


The use of Control Volume criteria and severity grade are associated with better therapeutic and prognostic informations in confront to the Neer classification.




Author contributions: the authors contributed equally

Conflict of interest

The authors declare that they have no conflict of interest



Ethical approval

All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee and with the 1964 Helsinki declaration and its later amendments or comparable ethical standards.

Informed consent was obtained from all individual participants included in the study.
